Accuton Speaker Model

• 5” CERAMIC BASS-MIDRANGE
• Good dispersion up to 5 kHz
• Very high resolution
• Rubber surround
• Titanium VC former
• Flange 130x130mm
• Cut-out 116x116mm
• Depth 75mm

Znom 6 ohm
Re 5.9 ohm
Le@1kHz 0.4 mH
fs 33.6 Hz
Qms 3.29
Qes .23
Qts .215
Mms 9.3 g
Cms 2.42 mm/N
