Accuton Speaker Model

Part Number
5” CERAMIC BASS-MIDRANGE C89-T6

• 5” CERAMIC BASS-MIDRANGE
• Good dispersion up to 5 kHz
• Very high resolution
• Rubber surround
• Titanium VC former
• Flange 130x130mm
• Cut-out 116x116mm
• Depth 75mm

Znom 6 ohm
Re 5.9 ohm
Le@1kHz 0.4 mH
fs 33.6 Hz
Qms 3.29
Qes .23
Qts .215
Mms 9.3 g
Cms 2.42 mm/N

Sd 83.3 cm 2
BL 7.1 N/A
Vas 23.5 ltrs
Xmax 3.1 mm peak
VC Ø 37.7 mm
Sensitivity
1W / 1m 89.2 dB
Nom. Power 100 W
Net weight 1800 g
