Accuton Speaker Model

Part Number
7” CERAMIC BASS-MIDRANGE C92-6

• 7” CERAMIC BASS-MIDRANGE
• Good dispersion up to 4 kHz
• Very high resolution
• Rubber surround
• Aluminum VC former
• Flange 180mm
• Cut-out 146mm
• Depth 87mm

Znom 8 ohm
Re 6.1 ohm
Le@1kHz 0.4 mH
fs 29 Hz
Qms 1.44
Qes .59
Qts .42
Mms 13.8 g
Cms 2.18 mm/N

Sd 133 cm 2
BL 5.1 N/A
Vas 54.8 ltrs
Xmax 4.0 mm peak
VC Ø 39 mm
Sensitivity: 1W / 1m 86 dB
Nom. Power 130 W
Net weight 2450 g
