Accuton Speaker Model

Part Number
7” CERAMIC BASS-MIDRANGE C95-T6

• 7” CERAMIC BASS-MIDRANGE
• Good dispersion up to 3 kHz
• Very high resolution
• Rubber surround
• Titanium VC former
• Flange 180mm
• Cut-out 146mm
• Depth 108mm

Znom 6 ohm
Re 5.9 ohm
Le@1kHz 0.73 mH
fs 32 Hz
Qms 4.0
Qes .30
Qts .279
Mms 13.8 g
Cms 1.36 mm/N

Sd 133 cm 2
BL 8.32 N/A
Vas 34.2 ltrs
Xmax 5.0 mm peak
VC Ø 38 mm
Sensitivity 1W / 1m 89.1 dB
Nom. Power 130 W
Net weight 2450 g
