Accuton Speaker Model

Part Number
8” CERAMIC WOOFER C220-T6

• 8” CERAMIC WOOFER
• Low resonance
• Suitable as subwoofer
• High excursion
• Rubber surround
• Titanium VC former
• Flange 222mm
• Cut-out 188mm
• Depth 120mm

Znom 6 ohm
Re 5.9 ohm
Le@1kHz 0.61 mH
fs 20.4 Hz
Qms 4.49
Qes 0.29
Qts 0.27
Mms 31.9 g
Cms 1.91 mm/N

Sd 233 cm 2
BL 9.1 N/A
Vas 144 ltrs
Xmax 5.2 mm peak
VC Ø 38 mm
Sen si tiv ity
1W / 1m 89.6 dB
Nom. Power 150 W
Net weight 2950 g
