Accuton Speaker Model

• 5" CERAMIC BASSMIDRANGE

• Good response up to 5 kHz

• Very high resolution

• Rubber surround

• Titanium VC former

• Flange 152mm

• Cut-out 122mm

Znom 8 ohm

Re 7.6 ohm

Le@1kHz 0.93 mH

fs 35.6 Hz

Qms 5.82

Qes .27

Qts .26

Mms 9.0 g

Cms 2.22 mm/N

Sd 76.0 cm2

BL 7.23 N/A

Vas 17.9 ltrs

Xmax - mm peak

VC Ø 25 mm

Sensitivity 1W / 1m 86.7 dB

Nom. Power 130 W

Net weight 1800 g
