Accuton Speaker Model

Part Number
5” CERAMIC BASS-MIDRANGE C88-6

• 5” CERAMIC BASS-MIDRANGE
• Good dispersion up to 4 kHz
• High resolution
• Good excursion
• Wide bandwidth
• Flange 130x130mm
• Cut-out 116x116mm
• Depth 75mm

Znom 6 ohm
Re 5.9 ohm
Le@1kHz .16 mH
fs 36 Hz
Qms 1.04
Qes .54
Qts .35
Mms 8.8 g
Cms 2.23 mm/N

Sd 80.1 cm 2
BL 4.67 N/A
Vas 20 ltrs
Xmax 3.0 mm peak
VC Ø 37.7 mm
Sensitivity: 1W / 1m 86 dB
Nom. Power: 120 W
Net weight: 1800 g
