Accuton Speaker Model

• 1" CERAMIC DOME TWEETER

• High efficiency version

• 4mm Underhung Neodymium magnet

• Heavy zinc front plate

• Ferrofluid - reduced

• Flange 82x 82mm

• Cut-out 64 x 64mm

• Depth 56mm

Znom 6 ohm

Re - ohm

Le@1kHz - mH

fs 1360 Hz

Qms -

Qes -

Qts -

Mms - g

Cms - mm/N

Sd 6.1 cm2

BL - N/A

Vas - ltrs

Xmax - mm peak

VC Ø 16.4 mm

Sensitivity

2.83V / 1m 92 dB

Nom. Power 120 W

Net weight - g
