1.2” CERAMIC DOME TWEETER C23-6

• 1.2” CERAMIC DOME TWEETER
• Wide bandwidth
• Response to @23kHz
• Very high resolution
• Very low resonance
• Ferrofluid loaded
• Flange 106 x106mm
• Cut-out 89x 89mm
• Depth 67mm

Znom 6 ohm
Re 6.1 ohm
Le@1kHz 0.04 mH
fs 350 Hz
Qms -Qes
-Qts
-Mms .4 g
Cms - mm/N

Sd 8.5 cm 2
BL - N/A
Vas - ltrs
Xmax - mm peak
VC Ø 19.4 mm
Sensitivity: 1W / 1m 89.5 dB
Nom. Power 100 W
Net weight 980 g
